Plastics Raw Material PA6 GF15 Manufacturer for Auto Parts Factory
Product DescriptionProduct descriptionPA6+15%Glass fiber reinforcedPerformance characteristics15%GF;High mechanical strength;Good electronical performancePhysical propertyDensityg/cm3ISO 1183 1.24Filler content%ISO 1172 GF15Mold shrinkage%ISO 294Parallel0.4Vertical0.9Mechanical propertyTensile stren......
Send Inquiry
Product Description
Product description
PA6+15%Glass fiber reinforced
Performance characteristics
15%GF;
High mechanical strength;
Good electronical performance
Physical property
| Density | g/cm3 | ISO 1183 | 1.24 | |
| Filler content | % | ISO 1172 | GF15 | |
Mold shrinkage | % | ISO 294 | Parallel | 0.4 |
| Vertical | 0.9 |
| Tensile strength | MPa | ISO 527 | I type sample 50mm/min | 125 |
| Elongation at break | % | ISO 527 | I type sample 50mm/min Gauge length 50mm | 3.5 |
| Flexural strength | MPa | ISO 178 | 23ºC 10mm/min | 160 |
| Flexural modulus | MPa | ISO 178 | 23ºC 10mm/min | 5100 |
| Izod impact strength(notched) | KJ/m2 | ISO 180 | 23ºC | 7 |
| Charpy impact strength(unnotched) | KJ/m2 | ISO 179 | 23ºC | 55 |
| Melting point | ºC | ISO 11357-1 | 220 | |
| HDT | ºC | ISO 75 | 0.45MPA | 210 |
| 1.8MPA | 190 |
| UL Flammability | Class | UL-94 | HB | |
| GWIT | IEC60695-2-13 | - |
Applications
Mechanical parts;
Auto parts
Overview:
Rynite thermoplastic polyester resins are typically used in demanding applications in the automotive, electrical and electronics, appliances where they successfully replace metals and thermosets, as well as other thermoplastic polymers.
Common features of Rynite thermoplastic polyester include mechanical and physical properties such as excellent balance of strength and stiffness, dimensional stability, creep resistance, heat resistance, high surface gloss and good inherent electrical properties at elevated temperature. It can be processed over a broad temperature range and has excellent flow properties.
We can give discount according to your order quantity.
We also have good experience in transportation both by air and ocean to overseas.
Automotive - Engine Covers/Housings
Cable Insulation and Jacketing
Electrical & Electronic Plastics
Electrical Encapsulation Materials
Electrical Insulation Polymers
Electrical Motor Insulation
Electronic & Electrical Connectors
High-Performance Materials for 3D Printing
Innovative Furniture Design
Mobile Phone Housing & Components
Cylinder Head Cover Gaskets
Photovoltaic Panels and Parts
Plastics For Sporting Goods
Polymers For Appliances
Railway Technology for the Long Haul
Thermoplastic Tubing and Elastomeric Hose
Transformer Insulation
We can give discount according to order quantity.
Package picture:
Elvamide 8063
Multipurpose nylon multipolymer resin
Melting Point: 158 degree centigrade
Specifications:
1.We are very experienced with this field(more than 10 years);
2.Good after-sales service;
3.100% Virgin material;
4.We accept sample order for testing;
5.Strong supply ability.
We need your following information to quote:
End user name ?
OEM/ODM name ?
Project name ?
Application ?
Uses?
Processing Method?
Appearance Color ?
Potential vol ? (mt/year)
Welcome to.......
Any questions pls feel free to contact to us !
