Waterproof 1220 *2440mm PVC Foam Board for Building Material

Product Description

Send Inquiry

> Products > Plastic Sheet, Board & Panel > Waterproof 1220 *2440mm PVC Foam Board for Building Material

Product parameters Type: PVC Free Foam SheetPVC Celuka Foam SheetPVC Co-Extrusion Foam Sheet Size915*1830mm; 1220*2440mm; 1560*3050mm; 2050*3050mm or any size you wantThickness1-30mmDensity0.33-1.0g/cm3Colormainly white or other colors Advantages1) Resistant to chemical......

915*1830mm; 1220*2440mm; 1560*3050mm; 2050*3050mm or any size you want

0.33-1.0g/cm3

mainly white or other colors

Advantages

1) Resistant to chemicals and corrosion;
2) Homogeneous, glossy and smooth surface;

3) Good deep-drawing qualities;
4) Good for foiling;

5) Easy workability;
6) Low flammability;

7) Impact-resistant or increased impact resistance;
8) Weather resista

Application

1.Advertisement: exhibition & display,digital printing,silk screen printing,engraving materials,sign board, etc.
2.Furniture:office furniture,cabinet,bath cabinet,etc.

3.Building & decoration: outdoor and indoor decoration; partition board in office & house;
4.Industrial Application:thermoforming products,refrigeratory warehouse project,environmental protection.
5. Transportation: interior decoration material for buses, trains, metro, steamships and airplanes.

Product parameters

Type:	PVC Free Foam Sheet
	PVC Celuka Foam Sheet
	PVC Co-Extrusion Foam Sheet

Technical Data
Density, g/cm³ ISO 1183		0,5
Yield Stress, MPa DIN EN ISO 527		13
Yield Strain, % DIN EN ISO 527		3
Tensile strain at break, % DIN EN ISO 527		25
E-modulus of elasticity in tension, MPa DIN EN ISO 527		750
Impact strength, kJ/m² DIN EN ISO 179		15
Notched impact strength, kJ/m² DIN EN ISO 179		-
Ball indentation hardness, MPa DIN EN ISO 2039-1		-
Shore hardness D ISO 868		48
Coefficient of linear thermal expansion, K-1, DIN 53752		0,8 x 10^-4
Thermal conductivity, W/m×K DIN 52612		0,0709
Fire behaviour DIN 4102		B 1³
Dielectic strength, kV/mm VDE 0303 - 21		-
Surface resistivity, Ohm DIN IEC 60167		>10¹⁵
Temperature range, °C		0 bis +60
Physiologically acceptable acc. to BgVV¹ and FDA² (USA)		no
¹ Federal Health Institute for the protection of consumers and veterinary medicine ² Food and Drug Administration ³ DIN 4102-B1 certificate for sheets from 6 mm up to 19 mm thickness
Handling
Welding	possible
Glueing, glassfibre reinforcing	yes
Lacquering, printing	yes
Warm bending	good

Specification

Product	pvc foam sheet
Material	Polyvinychlride
Surface	Glossy,Matte,Colored
Thickness	1-35mm
Dimension	*915mm1830mm**
	*1220mm2440mm**
	*1560mm3050mm**
	*2050mm3050**
Color	White,Colored
Density	0.3g/cm³-0.8g/cm³
Certificate	SGS
Payment	T/T 30% as deposit, and 70% balance against bill of lading copy; or L/C at sight.
Packaging	Plastic bags or brown paper; pallet; wood case, carton box
Delivery Time	it will take 7 to 15 days for 120ft, 15-20 days for 140ft , after receiving your advance payment.

Features

1. Waterproofing.
2. Fire retardant and self-extinguishing.
3. Heat preservation.
4. Sound-insulated.

5. Insulation.
6. Non-corrosion.
7. Non-toxic.
8. Tough, rigid with the high impact strength.
9. Stable color retention.

Advantages:

1) Resistant to chemicals and corrosion;
2) Homogeneous, glossy and smooth surface;

3) Good deep-drawing qualities;
4) Good for foiling;

5) Easy workability;
6) Low flammability;

7) Impact-resistant or increased impact resistance;
8) Weather resista

FAQ

Q1. What is your kinds of packing?
A: Plastic bags or brown paper; pallet; wood case, carton box;.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% balance against bill of loading copy; or L/C at sight.

Q3. How about your delivery time?
A: Generally, it will take 7 to 15 days for 1*20ft, 15-20 days for 1*40ft after receiving your advance payment.

Q4. Can you produce according to our samples?
A: Yes, you can send samples to us and we can check your quality and produce as per your samples or technical drawings.

Q5. Can I get samples?
A: Yes, small samples are usually free with express service expense at customer's cost.

Q6: Is factory visit or inspection acceptable?
A: Yes,factory visit is always welcomed and inspection like third-party inspection okay.

Q7: Do you attend any expo?
A: Yes, usually we attend sign expos in Shanghai twice in a year (one in March and the other in September). And we attended Sign Asia expo in IMPACT, THAILAND. In future we will add China Import and Export Fair (Canton Fair) into our exhibition list, also some international expos which will be hold in different countries.

Q8: Can you produce lead-free pvc?
A: Yes, both with-lead or lead-free pvc foam board okay with us, depending on customer needs.

Q9: How about the after-sale service?
A: If there has any quality problems when you receive our products, show us photos and after discussing we will afford the lost from next order.

Welcome to contact us!
