Product Description

encupsulant and potting compound liquid silicone

Encupsulant and potting compound liquid silicone is a newly insulating material silicon of silicon compounds.

It cures with no heat, no corrosion and little shrinkage. It can be applied to the sealing and pouring of various electronic components, and then forming insulation system.

Features of encupsulant and potting compound liquid silicone

1,Room temperature vulcanize, and easy to operate;

2,Maintain flexibility at a wide temperature range, and excellent insulation performance;

3,Waterproofing, moisture-proof, mouldproof, dustproof, and fixed components;

4,Resistance to Chemical dielectric, anti-yellowing, resistance to climate ageing.

Applications of liquid silicone for potting

Automotive vehicle lighting
Display for sports and advertising
Back lighting for LCD screens
Aviation display lighting
Airport lighting
Rail & road signalling systems
Architectural lighting
Medical

Encupsulant and Potting Compound Liquid Silicone

Technical Parameters

Features		Part A	Part B
Before Curing	Appearence	Transparent Fluid	transparent Fluid
	Viscosisty(25°Ccps)	600±200	800±200
Operation features	Mixing Ratio	1to1
	Viscosisty(after mixing) (cps)	600~1000
	Operating Time(25°C hr)	3
	Curing time (min,25°C)	8
	Curing time(80°C hr)	20
After Curing	Hardness(Shore A)	0
	Thermal conductivity [W(m·K)]	≥0.2
	Dielectric Strength(KV/mm)	≥25
	Permittivity(1.2MHz)	3.0~3.3
	Volume Resisivity(Ω·cm)	≥1.0×10¹⁶
	linear expansibility [m/(m·K)]	≤2.2×10^-4
	Fire Resistance	94-V1

(Pls note the above data for this product in 25 °C temperature, 55 percent humidity conditions, for reference. The accurate data is measured by customers to when using.)

The silicone will with stand all weathers and provide protection during transportation of mobile units.
